Wu Tong Zhuang Colliery of Fengfeng Group of Jizhong Energy Group
Profiled Rail Collie Car, 2 sets
●The first set: profiled rail coolie car, , Max. gradient 19°, rail gauge: 600m, rail: SMJ160 profiled rail,mainly for the transport of material and personal, put into use in 2009.
●The second set: profiled rail coolie car, transport distance 1300m, Max. gradient 18°, rail gauge 600mm, rail: SMJ140 profiled rail, the joint is by clamp plate, mainly for the transport of material and personal, put into used in 2011.
Wannian Colliery of Fengfeng Group of Jizhong Energy Group
The transport distance 1700m, there are 5 horizontal turns, the max. is 15°, 4 vertical turns, the max. is 12°. The section dimensions: 3.5m×3.2m. Put into use in 2011, so far, transport supporters 132pcs, and also be used to transport material and personal.
The Great Wall Colliery of Xinwen Mining Group
The transport distance 1700m, the max. gradient is 15°, the max. transport capacity is 21tons hydraulic supporter, put into use in 2011, has been used to transport supporters 90 pcs, and also be used to transport material and personal.
Lu Ning Coal of Lu’an Group
2005 used the general rail coolie car, in January 2011, change to SMJ160 profiled rail, the transport distance is 2300m, the max gradient is 16°, used to transport material and hydraulic supporter.
Yu Wu Coal of Lu’an Group
There are 4 sets of profiled rail coolie car
● The first set: the transport distance 1900m, the max gradient 6°, the max. load transported is 28 tons, every day full load operation so far.
●The second set: the transport distance2200m, the max gradient 6°, the max. load transported is 28 tons, every day full load operation so far.
●The third set: the transport distance2200m, the max gradient 6°, the max. load transported is 28 tons, every day full load operation from April 2011 so far.
●The fourth set: the transport distance1600m, the max gradient 10°, the max. load transported is 28 tons, every day full load operation from 2011 so far.
Zhang Cun Colliery of Lu’an Group
There are 2 sets of channel steel coolie car, 1 set of profiled coolie car
●The first set: it is the first cable driven coolie car in China, the transport distance is 3800m, the max gradient is 13.5°, every shift full operation, the max. loading capacity is 22 tons, put into use in 2000, has transported hydraulic supporters 3000pcs and made a record of the max. transport distance of coolie car.
●The second set: channel steel coolie car, the transport distance 3500m, the max gradient 10°, every shift full operation, the max. loading capacity is 22 tons.
●The third set: SMJ160 profiled rail coolie car, the transport distance is 2200m the max. gradient is 6.3°, is Being installed and adjusted.
